SN/T 1588.3-2013
GB
ENTRY-EXIT INSPECTION AND QUARANTINE INDUSTRY
STANDARD OF THE PEOPLE’S REPUBLIC OF CHINA
Replacing SN/T 1588.3-2006
Rules for the inspection of luminaires for import and
export - Part 3. Particular requirements of luminaries
for swimming pools and similar applications
ISSUED ON. NOVEMBER 6, 2013
IMPLEMENTED ON. JUNE 1, 2014
Issued by. General Administration of Quality Supervision, Inspection and
Quarantine of the People's Republic of China
Table of Contents
Foreword ... 3
Introduction ... 5
1 Scope ... 6
2 Normative references ... 6
3 Terms and definitions ... 7
4 General requirements ... 7
5 Inspection... 7
6 Qualified batch determination and validity period ... 13
Rules for the inspection of luminaires for import and
export - Part 3. Particular requirements of luminaries
for swimming pools and similar applications
1 Scope
This Part of SN/T 1588 specifies the requirements, sampling, inspection as well
as determination of inspection results of import-export luminaries for swimming
pools and similar applications.
This Part is applicable to the import and export inspection of stationary
luminaires used in or in contact with water, such as swimming pool sinks,
fountains, paddling pools and garden pools, of luminaires using tungsten
filament lamps and LEDs.
This Part is not applicable to the import and export inspection of luminaires that
are not in contact with water (e.g., installed behind glass panels that are part of
the fixture) or portable luminaires.
2 Normative references
The following referenced documents are indispensable for the application of
this document. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any
amendments) applies.
GB/T 2828.1, Sampling procedures for inspection by attributes - Part 1.
Sampling schemes indexed by acceptance quality limit(AQL) for lot-by-lot
inspection
GB 5013.1, Rubber insulated cables of rated voltages up to and including
450/750 V - Part 1. General requirements
GB 7000.1-2007, Luminaires - Part 1. General requirements and tests
GB 7000.218-2008, Luminaires - Part 2-18. Particular requirements -
Luminaries for swimming pools and similar application
GB 17625.1, Electromagnetic compatibility – Limits - Limits for harmonic
current emissions (equipment input current ≤16 A per phase)
GB 17743, Limits and methods of measurement of radio disturbance
characteristics of electrical lighting and similar equipment
GB/T 20145, Photobiological safety of lamps and lamp systems
SN/T 1588.2, Rules for the inspection of luminaires for export and import -
Part 2. General requirements
3 Terms and definitions
For the purposes of this document, the terms and definitions defined in SN/T
1588.2 as well as the followings apply.
4 General requirements
4.1 Safety requirements
The safety requirement for luminaries for swimming pools and similar
applications shall comply with the provisions of GB 7000.218-2008 and GB
7000.1-2007. Country (regional) differences shall be considered when
applicable.
4.2 Electromagnetic compatibility requirements
When applicable, the electromagnetic compatibility requirements for luminaries
for swimming pools and similar applications shall comply with the provisions of
GB 17743 and GB 17625.1. Country (regional) differences shall be considered
when applicable.
4.3 Optical radiation safety requirements
When applicable, the optical radiation safety requirements for luminaries for
swimming pools and similar applications shall comply with the provisions of
GB/T 20145-2006. Country (regional) differences shall be considered when
applicable.
4.4 Other requirements
When applicable, it shall also meet the energy efficiency and environmental
protection requirements of the technical regulations of the country (region) used.
5 Inspection
5.1 Selection of inspection supervision mode
The inspection supervision mode for particular requirements for import-export
luminaries for swimming pools and similar applications shall be either the
sampling inspection mode, the type test mode or the conformity verification
mode according to relevant national regulations and specific situation.
5.2 Inspection method
The inspection method under different inspection and supervision modes is.
- sampling inspection mode. batch-by-batch or random batch sampling
inspection;
- type test mode. type test + random batch sampling inspection;
- conformity verification mode. conformity verification + random batch
sampling inspection.
5.3 Type test
5.3.1 Sampling
Randomly take representative samples from the stereotyped products
according to the quantity specified in the product standard for testing.
5.3.2 Inspection content and requirements
5.3.2.1 Safety testing
Test all applicable items according to the requirements of GB 7000.218-2008.
When applicable, country (regional) differences shall be considered.
5.3.2.2 Electromagnetic compatibility testing
When applicable. Test all applicable items according to the requirements of GB
17743 and GB 17625.1. Country (regional) differences shall be considered.
5.3.2.3 Optical radiation safety testing
When applicable. Test all applicable items according to the requirements of
GB/T 20145. Country (regional) differences shall be considered.
5.3.2.4 Other testing
When applicable, it shall also be tested for energy efficiency and environmental
protection in accordance with the technical regulations of the country (region)
in use.
5.3.3 Result determination and validity period
If all tests are qualified, the type test shall pass, otherwise it shall fail.
