QC/T 29087-1992
INDUSTRY STANDARD OF THE
PEOPLE’S REPUBLIC OF CHINA
QC/T 29087-92
Limit deviation for undeclared tolerance size of
automobile welding processing parts
ISSUED ON: MAY 21, 1992
IMPLEMENTED ON: JUNE 01, 1993
Issued by: China National Automotive Industry Corporation
Table of Contents
1 Subject content and scope of application ... 3
2 Limit deviation for undeclared tolerance size of welding processing... 3
Additional information: ... 5
Limit deviation for undeclared tolerance size of
automobile welding processing parts
1 Subject content and scope of application
This Standard specifies the limit deviation for undeclared tolerance size in the
automobile parts affected by welding procedure.
This Standard applies to the limit deviation for undeclared tolerance size and
angle formed after welding processing.
This Standard does not apply to the welding size and weld size checked
according to the master model.
2 Limit deviation for undeclared tolerance size of
welding processing
2.1 The limit deviation for the undeclared tolerance of linear size shall be in
accordance with Figure 1 and Table 1.
Figure 1
