Scope

This Part of GB/T 32322 establishes the boundary dimensions and tolerances for
series 1, 2 and 3 of linear motion rolling bearings, profiled rail guides.
These bearings consist of profiled rails with carriages, which can support forces from
all perpendicular directions and moments around all axes and consist of recirculating
rolling elements. The internal design of these profiled rail guides is at the discretion of
the manufacturer.
An assembly, as specified by the manufacturer, can comprise one or more carriages
on a profiled rail. Therefore, the interchange or combination of these elements can only
be carried out within the limits permitted by the manufacturer.
