Scope

This Part of GB/T 21437 establishes a bench top test for the evaluation of the immunity
of devices under test (DUTs) to transient transmission by coupling via lines other than
supply lines. The test transient pulses simulate both fast and slow transient
disturbances, such as those caused by the switching of inductive loads and relay
contact bounce.
Three test methods are described in this Part.
- Capacitive coupling clamp (CCC) method;
- Direct capacitive coupling (DCC) method;
- Inductive coupling clamp (ICC) method.
Note. The applicability of the three test methods is shown in Table 1.
Only one test method need be selected for slow transients and only one method need be
selected for fast transients.
This Part applies to road vehicles fitted with nominal 12 V, 24 V or 42 V electrical systems.
For transient immunity, Annex B provides recommended test severity levels in line with the
functional performance status classification (FPSC1) principle described in GB/T 21437-1.
