GB/T 19582.2-2008: Modbus industrial automation network specification -- Part 2: Modbus protocol implementation guide over serial link

Delivery: 9 seconds. Download (and Email) true-PDF + Invoice.
Get Quotation: Click GB/T 19582.2-2008 (Self-service in 1-minute)
Newer / historical versions: GB/T 19582.2-2008

Preview True-PDF

Scope

Modbus is an application-layer message transport protocol at Layer 7 of the OSI model,
providing client/server communication between devices connected to different types of buses
or networks. It also standardizes the protocol over serial links to facilitate the exchange of
Modbus requests between a master and one or more slaves.
The goal of this Part is to propose a Modbus protocol over serial links for system designers to
use when implementing a serial link-based Modbus protocol.
This Part will facilitate interoperability between devices using the Modbus protocol.
This Part also supplements GB/T 19582.1-2008, as shown in Figure 1.
Clause 9 defines different implementation levels of "Modbus Serial Link". The specifications
for each level are all the requirements that a device must comply to be considered within that
level.
Figure 1 – Overview of Modbus protocol text

Basic Data

Standard ID	GB/T 19582.2-2008 (GB/T19582.2-2008)
Description (Translated English)	Modbus industrial automation network specification -- Part 2: Modbus protocol implementation guide over serial link
Sector / Industry	National Standard (Recommended)
Classification of Chinese Standard	N10
Classification of International Standard	25.040
Word Count Estimation	38,364
Date of Issue	2008-02-27
Date of Implementation	2008-09-01
Older Standard (superseded by this standard)	GB/Z 19582.2-2004
Regulation (derived from)	Announcement of Newly Approved National Standards No. 3 of 2008 (No. 116 overall)
Issuing agency(ies)	General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary	This standard specifies the serial link Modbus protocol, so that the system designer to achieve based on the serial link Modbus protocol is used. This section will promote the use of Modbus protocol interoperability between devices. This section is for GB/T 19582. 1-2008 supplement, specifically Figure 1. Defined in Chapter 9 of the "Modbus serial link " different implementations levels. Level requirement is to belong to a certain level and equipment must comply with all the requirements.
