Scope

This Part of GB/T 15054 specifies the profiles, diameters of miniature screw
threads as well as pitch general plan and basic dimensions.
This Part is applicable to miniature screw threads of general use of which the
range of nominal diameter is 0.3mm~1.4mm.
NOTE. The profile and tolerance of miniature screw threads with a nominal diameter range of
1mm~1.4mm (S) differ from those of ordinary screw threads (M).

Basic Data

Standard ID	GB/T 15054.1-2018 (GB/T15054.1-2018)
Description (Translated English)	Miniature screw threads -- Part 1: Profiles, general plan and basic dimensions
Sector / Industry	National Standard (Recommended)
Classification of Chinese Standard	J04
Classification of International Standard	21.040.30
Word Count Estimation	7,749
Date of Issue	2018-05-14
Date of Implementation	2018-10-01
Older Standard (superseded by this standard)	GB/T 15054.3-1994; GB/T 15054.2-1994; GB/T 15054.1-1994
Regulation (derived from)	National Standards Announcement No. 6 of 2018
Issuing agency(ies)	State Administration for Market Regulation, China National Standardization Administration
