DL/T 5056-2007: Technical Code of General Plan Design for Substation

Delivery: 9 seconds. Download (and Email) true-PDF + Invoice.
Get Quotation: Click DL/T 5056-2007 (Self-service in 1-minute)
Newer / historical versions: DL/T 5056-2007

Preview True-PDF

Scope

This Standard stipulates the basic technical requirements of general plan design for
substations.
This Standard is applicable to the general plan design for newly constructed or
expanded substations with the voltage level of 110 kV ~ 750 kV. The general plan
design for substations with the voltage level of above 750 kV, reconstructed
substations and converter stations may also take this as a reference.

Basic Data

Standard ID	DL/T 5056-2007 (DL/T5056-2007)
Description (Translated English)	Technical Code of General Plan Design for Substation
Sector / Industry	Electricity and Power Industry Standard (Recommended)
Classification of Chinese Standard	P62
Classification of International Standard	29.240.10
Word Count Estimation	74,785
Date of Issue	2007-12-03
Date of Implementation	2008-06-01
Older Standard (superseded by this standard)	DL/T 5056-1996
Quoted Standard	GB 50007; GB 50016; GB 50187; GB 50201; GB 50229; GB 50330; GBJ 22; DL/T 5032
Regulation (derived from)	NDRC Notice No. 81 of 2007
Issuing agency(ies)	National Development and Reform Commission
Summary	This standard specifies the general layout of substation design of the basic technical requirements. This standard applies to the voltage level of 110kV ~ 750kV substation new or expanded general arrangement design. Right above voltage level 750kV substation, substation and alterations converter station layout design can refer to the total use.
